<%NUMBERING1%>.<%NUMBERING2%>.<%NUMBERING3%> PRTG Manual: Notifying

PRTG Network Monitor keeps the administrator or other responsible persons informed about the current status of the network. There are several methods how the administrator can stay up to date.

Notifications

This is the most powerful information tool. Whenever PRTG discovers downtime, an overloaded system, threshold breaches (for example, a disk runs full), or similar situations, it can send a notification. Notifications use various methods with which you can be notified (for example, email, SMS, push messages, and others). After creating notifications in the system settings, you can select them on the notifications tab of probes, groups, devices, and sensors, as well as on the root group.

See Notifications section for more details and Setting Up Notifications Based on Sensor Limits: Example for a step-by-step guide.

Limits

In a sensor channel's settings, you can set limits to change the status of the sensor when certain limits are breached. This way, you can set, for example, a traffic sensor (typically never in an error status) to Down status whenever bandwidth values are measured that you consider critical. This sensor will then show up in the alarms list.

Alarms

The alarms list shows all sensors that are currently in a Down, Down (Acknowledged), Warning, or Unusual status. This is useful for keeping track of all irregularities in your network. In the table list, you can re-sort the items by clicking on the column's header items. See Alarms section for more details.

Logs

In the logs list, the log file with all monitoring events is shown. In a typical setup, a huge amount of log data is produced. As the activity of every single object is minuted, you can use this data to check exactly if your setup works as expected. See Logs section for more information.

Tickets

The tickets list shows items with important system information or action steps for the administrator to take. You should view every ticket and take appropriate actions. By default, an email is sent to the administrator for every new ticket that is created by the system or another user. If a ticket is assigned to a specific user, this user will get an email by default. See Tickets section for more information.
